Standard clevis load pins for pewag clevis system.
It is easy to operate, with an outstanding safety factor.
For a few parts special pins must be used (2nd table).
Standard clevis load pins for pewag clevis system.
It is easy to operate, with an outstanding safety factor.
For a few parts special pins must be used (2nd table).
|
Art No
|
Code
|
d x l (mm)
|
For accessory part
|
|
11.11PEW58951
|
KBS-KLH/KLHW PWH 6
|
7,5 x 17,5 + 7,4 x 16,5
|
KLH/KLHW-PWH 5/6
|
|
11.11PEW58952
|
KBS-KLH/KLHW PWH 7
|
9 x 22,5
|
KLH/KLHW-PWH 7
|
|
11.11PEW58953
|
KBS-KLH/KLHW PWH 8
|
10 x 22,5 + 10 x 23
|
KLH/KLHW-PWH 8
|
|
11.11PEW58950
|
KBS-KLH/KLHW PWH 10
|
13 x 31,5 + 12,5 x 29,5
|
KLH/KLHW-PWH 10
|
|
11.11PEW58954
|
KBS-KLH/KLHW PWH 13
|
16 x 42 + 16 x 37
|
KLH/KLHW-PWH 13
|
|
11.11PEW58955
|
KBS-KLH/KLHW PWH 16
|
21 x 51,5 + 20 x 52
|
KLH/KLHW-PWH 16
|
|
11.11PEW58989
|
KBS-KSS 7
|
8 x 22,5
|
KSS 7
|
|
11.11PEW58990
|
KBS-KSS 8
|
10 x 27,2
|
KSS 8
|
|
11.11PEW58991
|
KBS-KSS 10
|
12 x 32,2
|
KSS 10
|
|
11.11PEW58992
|
KBS-KSS 13
|
16 x 45,7
|
KSS 13
|
